Hyundai Veloster: Engine compartment
Hyundai Veloster 2011-2017 Owner's Manual / Your vehicle at a glance / Engine compartment
1. Engine oil filler cap
2. Engine oil dipstick
3. Brake/clutch fluid reservoir
4. Positive battery terminal
5. Negative battery terminal
6. Fuse box
7. Air
cleaner
8. Radiator cap
9. Engine coolant reservoir
10. Windshield washer
fluid reservoir
